How to Choose Pallet Racking in Singapore: Decision Matrix

Knowing how to choose pallet racking starts with your stock, not a catalogue. The right system follows from five facts you already have: SKU count, stock rotation, ceiling height, forklift fleet and budget. This blog will walk you through a decision matrix for selective, double deep, drive in and very narrow aisle racking, then applies it to a worked example.

What decides which pallet racking system fits your warehouse?

Five inputs decide it. Two describe your stock: how many SKUs you hold and how they must rotate. Three describe your site and resources: the clear height, the trucks you run or will buy and the budget.

The common mistake is starting from a rack type seen at another site. A third party logistics warehouse holding hundreds of client SKUs has a different problem from a distributor moving a dozen fast lines by the pallet load. The same steel will not serve both well.

Every option trades selectivity for density.

Selectivity is the share of pallets you can reach directly without moving another pallet first. Density is how many pallet positions fit on the floor. Selective and VNA racking keep every pallet reachable, while double deep and drive in give up access to gain positions.

What actually decides which pallet racking system fits your warehouse?

How do selective, double deep, drive in and VNA compare?

Use the matrix below to shortlist. A system that fails any row for your operation is usually out, however attractive its density. Specifications for each option sit on the page for NTL Storage’s pallet racking systems.

Decision factor Selective Double deep Drive in Very narrow aisle (VNA)
SKU count Any, including many SKUs with one pallet each Medium; each SKU should fill at least two pallets so a pair holds one line Low; each lane holds one SKU High, with every pallet reachable
Rotation Any: first in first out, first expired first out or random Last in, first out within each pair Last in, first out; a drive through layout gives first in, first out Any
Ceiling height Suits most units; reach trucks commonly lift 8 m to 10 m Limited by the deep reach truck’s lift and visibility at height Density comes from depth, not height Pays off in tall buildings, where height offsets truck and floor cost
Forklift Counterbalance in 3.2 m to 3.5 m aisles or reach truck in 2.6 m to 2.9 m Reach truck with pantograph or telescopic forks that reach the second pallet Truck drives into the lane, so drivers need training and rail protection Guided VNA truck in a 1.5 m to 1.8 m aisle with rail or wire guidance
Budget Lowest cost for a fully selective layout; no special truck More positions per aisle, plus a deep reach truck Most positions per square metre for bulk stock Highest upfront cost: trucks, guidance and a flatter floor

Pallet flow and push back racking sit outside this matrix. Pallet flow is the usual choice when FIFO matters and density is still needed, as in chilled and frozen food stores.

Selective racking

Selective pallet racking is the default because it accepts any stock profile and any rotation rule. Every pallet sits on its own beam pair, so a picker can reach any line without moving another. The cost is floor space, since every row of racking needs an aisle face.

It is also the easiest system to change later. Beam levels can be moved when pallet heights change, provided the supplier checks the new layout and the load notices are updated. For most SMEs on a JTC lease, that flexibility matters as much as density.

Double deep racking

Double deep pallet racking places two rows of pallets back to back on each side of the aisle. Each aisle therefore serves twice as many positions as in a selective layout. That roughly halves the number of aisles for the same number of positions, before allowing for column positions and the wider truck.

The rear pallet can only be reached once the front one is moved, so double deep works when each SKU fills at least two pallets. It needs a reach truck with pantograph or telescopic forks, which is a fleet decision as well as a racking one.

Drive in racking

Drive in racking removes the aisles inside a block. The truck drives into a lane and places pallets on rails either side, so one lane holds one SKU several pallets deep and several levels high. It gives the most positions per square metre of the four options.

The pallet loaded last is the first one out, unless the block is built as drive through with access at both ends, which makes drive in a poor fit for dated stock. Our selective vs drive in comparison covers that trade in detail. Lanes should be sized to the quantity of each line, because a half empty lane cannot take another SKU.

Very narrow aisle racking

Very narrow aisle racking keeps every pallet reachable while cutting aisles to about 1.5 m to 1.8 m. Guided turret or articulated trucks rotate the forks in the aisle instead of turning the whole truck, so the aisle only needs to be slightly wider than the load.

The savings come with conditions.

VNA needs its own trucks, rail or wire guidance and a floor flat enough for a tall truck to run safely. EN 15620 sets tighter installation tolerances for VNA racking, H/500 for upright out of plumb against H/350 for standard racking. VNA usually makes sense when the building is tall and floor space is the binding limit.

Should you choose for selectivity or for density?

Which site limits narrow the shortlist?

The matrix tells you which systems suit your stock. The building then decides how far each one can go.

Floor loading

Racking concentrates load through small baseplates, so a tall bay of heavy pallets can put more onto its own footprint than the slab is rated for, even when the average across the floor looks comfortable. JTC units at Defu Industrial City and YS-One, for example, are listed at 15 kN/m², and older flatted factories are often lower. An engineer should check baseplate loads against the slab before frame heights are fixed.

Sprinkler clearance and fire code

Usable height is not the roof height. The fire engineer checks the top of the stored load against the sprinkler design under SS CP 52 and the SCDF Fire Code 2023, including clearance below the sprinkler deflectors. A taller rack can need a sprinkler upgrade, so raise it at design stage.

Approvals and design standards

In JTC premises, the JTC Space Submission Handbook exempts racks from plan consent only up to 3.0 m high and 1.2 m wide, within 7.5 kN/m² or the design imposed load, whichever is lower. Most pallet racking goes past those limits and needs a submission.

SS EN 15512 sets the design rules for adjustable beam pallet racking, which covers selective, double deep and VNA layouts. Its scope excludes drive in and drive through racking, so ask a drive in supplier which design basis it uses and for the calculations behind its ratings.

How do you match the forklift to the racking?

The truck sets the aisle, and the aisle sets how many runs fit. A counterbalance forklift needs about 3.2 m to 3.5 m to turn with a loaded pallet, while a reach truck works in about 2.6 m to 2.9 m. Our guide to warehouse aisle width planning covers cross aisles and pallet overhang.

If you already run reach trucks, selective racking needs no new equipment. Double deep needs reach trucks with pantograph or telescopic forks, and VNA needs dedicated guided trucks. Price the trucks into the comparison, because a denser layout that needs a new fleet can cost more overall than a selective layout with a few more square metres.

How should budget and rent shape the choice?

Compare cost per pallet position across the whole system, including trucks, guidance and floor works, not only the racking steel. Cost per position usually falls as density rises, but density also costs you selectivity, flexibility and sometimes equipment.

Rent tilts the maths towards density. JTC’s Quarterly Market Report for 2Q 2026 put warehouse occupancy at 89.4% and warehouse rents 2.7% higher than a year earlier. With little spare space, adding positions inside the unit you already lease is often cheaper than taking a second unit.

Worked example: choosing racking for a mixed stock warehouse

The example below is illustrative, not a record of a specific NTL project. A building materials distributor leases a JTC unit with about 8 m clear height under the sprinklers. It runs two reach trucks and has no budget for new trucks this year.

Factor The distributor’s position What it rules in or out
SKU count About 220 lines: 190 slow lines at one or two pallets each, 30 fast lines at six to ten pallets each Slow lines need selective access; fast lines could go dense
Rotation Non perishable, no date control LIFO is acceptable for the fast lines
Ceiling height About 8 m clear Within reach truck range; not tall enough to make VNA pay
Forklift Two reach trucks, no pantograph forks Rules out VNA and, for now, double deep
Budget Racking only, no new trucks Favours selective plus drive in

The result is two zones. Selective racking holds the 190 slow lines, where every pallet must be reachable. A drive in block near dispatch holds the 30 fast lines, with lanes sized so each one holds a single line’s typical stock.

Double deep stays on the list for the fast lines when the trucks are next replaced. At that point, a reach truck with pantograph forks would let the same lines sit two deep in the selective runs without a separate drive in block.

What should you ask a supplier before you order?

Ask for the beam rating at your span, the frame rating at your actual beam levels and the design basis for each system in the quote. Check that baseplates, anchors, bracing and accessories are listed. Our guide to reading a racking quotation explains the eight specifications buyers most often miss.

A supplier should also say which approvals your unit needs and who prepares them. If those answers are vague, use our 12 questions for vetting a racking contractor before signing.

Planning pallet racking with NTL Storage

NTL Storage has supplied and installed pallet racking in Singapore since 2012, including selective, double deep, drive in and VNA layouts. Send us your SKU list with pallets per line, clear height, floor rating and trucks, and we will model the system mix against your unit before any steel is ordered.

FAQs About How To Choose Pallet Racking

What is the most common type of pallet racking in Singapore?

Selective pallet racking. It gives direct access to every pallet, works with the counterbalance and reach trucks most warehouses already run and suits any rotation rule. Denser systems such as double deep, drive in and VNA are chosen when the stock profile or floor space justifies the trade.

When should I choose double deep instead of selective racking?

Choose double deep when most SKUs fill at least two pallets and you need more positions without more floor space. Each aisle serves twice the positions, but the rear pallet is only reachable after the front one moves, and you need a reach truck with pantograph or telescopic forks.

Is drive in racking suitable for food storage?

Only for stock where rotation does not matter. Drive in works last in, first out, so the oldest pallet can sit at the back of the lane. For dated food, use selective or pallet flow racking, or a drive through layout loaded from one end and emptied from the other.

How tall does a warehouse need to be for VNA racking?

There is no fixed minimum, but VNA pays off in tall buildings, where extra levels offset the cost of guided trucks, guidance rails or wire and a flatter floor. In a unit of about 8 m clear height, selective racking with reach trucks usually gives a better return.

Does pallet racking need approval in a JTC unit?

Usually. JTC exempts racks from plan consent only up to 3.0 m high and 1.2 m wide, with gross weight within 7.5 kN/m² or the design imposed load and a 1.2 m clear passageway. Most pallet racking exceeds those limits, so it needs a submission.

What information do I need before asking for a racking quote?

Prepare your SKU list with pallets per line, pallet size and maximum weight, clear height under the sprinklers, the floor rating and the trucks you run. With those, a supplier can compare layouts on positions and cost instead of quoting a generic system.
